Specification	Details
Product Name	0.5% Molybdenum Manganese Steel Hydrocone Liner Set (Mantle & Concave for 36-inch Hydrocone), by Novin Maseh-Saz; compatible with Delta / Sandvik models
Material & Composition	Austenitic Manganese Steel (11–14% Mn, 0.4–0.6% Mo, 0.8–1.2% C); optional Ni-Hard for extreme wear
Hardness	HB 180–220 (as-cast); HB 375–525 (after work); Rockwell C 56–61 (surface hardened)
Operating Temperature	Maximum 80–145°C (oil cooling); continuous: 20–100°C
Dimensions	Mantle: Ø400–600 mm, Length 500–800 mm; Concave: Ø900–1150 mm, Height 300–500 mm (36-inch model)
Approx. Weight	Mantle: 150–300 kg; Concave: 200–375 kg; Full set: 350–675 kg
Throughput Capacity	100–190 t/h (0.5% Mo alloy, depending on CSS 8–48 mm)
Compressive Strength	165–230 MPa (manganese steel); lifespan: 700–1800 tons (18% longer with 0.5% Mo)
Color & Finish	Gray/Black (anti-corrosion powder coating); machined surface
Application Method	Press-fit installation on hydrocone shell/shaft; CSS adjustment via hydraulic system
Surface & Tolerance	Surface roughness: Ra 1.6–3.2 μm; tolerance: ±0.03 mm; clearance: 0.5–1 mm
Wear Resistance	High (28% longer lifespan with 0.5% Mo; suitable Mohs hardness 6–8; material loss <5%)
Thermal Resistance	Excellent; up to 145°C without deformation
Manufacturing Process	Casting / Machining (from manganese billets) + heat treatment (quenching); Profile: Standard / High-Mn

Additional information

Initial consultation and information exchange

Place an order

Product loading and shipping

Applications

Primary use: Fixed (bowl liners) and moving (cone liners) components in hydrocone crushers for secondary crushing
Industries / Locations:
- Mining: limestone and granite operations in Kenya
- Cement production: Nairobi & Mombasa
- Construction: concrete and asphalt aggregate production
Types:
- Concave (Fixed / Bowl Liner)
- Mantle (Movable / Cone Liner)

Extended wear life: 18–28% longer lifespan (700–1800 tons) compared to standard liners due to 0.5% Mo content
Consistent output: Controlled CSS producing 4–48 mm uniform aggregates
Market compatibility: Fits modern, Delta, and Sandvik hydrocone models commonly used in Kenya
Cost-effective: Approximately 200 million IRR vs. OEM 400+ million IRR
Easy installation: Press-fit design allows setup in ~1 hour
High-temperature resistance: Suitable for warm and humid climates up to 145°C

Installation: Mount on shell/shaft; adjust CSS; ensure leveling ±0.05 mm (~1 hour)
Maintenance: Lubricate every 200 hours; replace if wear >5 mm; monitor temperature (<145°C)
Transport & Handling: Maximum 675 kg per trailer set; 10-ton crane recommended
