Hydrocone crusher is one of the most widely used mining machines for secondary and tertiary crushing of all types of hard rocks. The conical design and high power of this hydrocone machine have made it widely used in mines, sand and gravel workshops and construction projects. Novin Masesaz Company, as a reputable supplier, offers various hydrocone models along with after-sales service and fast supply of parts. You can contact our experts to inquire about the price of hydrocone and choose the most suitable model.
| Device model | Inlet size (inches) | Production capacity (tons per hour) | Output product size (mm) | Engine power (kW) | Application type |
|---|---|---|---|---|---|
| Hydrocon 2/36 | 36×2 | 40–90 | 12–25 | 90–110 | Secondary crushing of semi-hard rocks |
| Hydrocon 3/36 | 36×3 | 60–120 | 12–30 | 110–132 | Secondary and tertiary crushing, sand and gravel |
| Hydrocon 3000 | 45 | 120–200 | 12–35 | 160–185 | Medium to large mines |
| Hydrocon 4000 | 45 | 180–250 | 12–40 | 185–200 | Iron ore and hard rock mines |
| Hydrocon 5 (Crusher) | 50 | 200–300 | 20–50 | 200–220 | Primary/secondary crushing of rubble |
| Hydrocon 8 (Crusher) | 54 | 300–400 | 25–60 | 220–250 | Large mines, crushing hard rock rubble |
| Superior Hydrocone (Coarse Crusher) | 36–54 (depending on model) | 250–500 | 25–70 | 250–300 | Primary crushing, alternative to gyratory |
| Hydrocone crusher (sand maker) | 36 | 60–120 | 0–5 | 90–110 | Production of fine-grained crushed sand and gravel |
The cone crusher is one of the most important secondary and tertiary crushing machines in sand and mineral processing lines. With its conical design and hydraulic lubrication system, this machine crushes hard rocks such as granite, basalt, silica, and even iron ore with high capacity. Depending on the model, the production capacity of the cone crusher varies between 60 and 300 tons per hour and the inlet size is between 36 and 54 inches.
The price of a hydro crusher depends on various factors and a fixed rate cannot be stated for it. Production capacity, inlet and outlet size, quality of body material and internal parts, brand and engine power are among the most important factors that affect the price of a hydro crusher. In addition, the cost of transportation, installation and after-sales service also play a role in determining the final price. For expert advice and up-to-date price inquiries, contact Novin Masesas experts.
One of the important advantages of a hydraulic press is easy access to spare parts and accessories. Using original parts increases the life of the machine, reduces repair costs, and prevents production line downtime.
| Piece | Application |
|---|---|
| Mantel | Stone crushing and abrasion resistance |
| Kankyo | Stone crushing and granulation production |
| Head Center | Guiding the stone to the cone and crushing it |
| Hydraulic jack | Adjusting the outlet opening and protecting the device |
| Hydraulic valve | Oil flow control and safety |
| Main shaft | Power transmission and cone movement |
| Bushes | Lubrication and friction reduction |
| Pinion and crank gear | Power transmission from motor to cone |
| Electromotor | Energy supply and cone rotation |
| Electrical panel | Performance and safety control |
| Bearings | Shaft support and wear reduction |
| O-rings and washers | Hydraulic system sealing and protection |
The hydrocone is a cone crusher that performs the crushing process in a staged and controlled manner. Its function is as follows:
| property | Hydrocone | Qubit |
|---|---|---|
| Type of grinding | Cone, compression and friction grinding | Impact, crushing by direct impact |
| Main application | Secondary and tertiary crushing of hard and semi-hard rocks | Primary and secondary crushing of medium and soft rocks |
| Production capacity | High (60 to 400 tons per hour depending on model) | Medium (50 to 200 tons per hour) |
| Output product size | Adjustable and uniform | More irregular grain size than hydrocone |
| Energy consumption | Less than qubits for the same capacity | Higher for the same capacity |
| Wear of parts | Lower (less wear parts) | Mostly due to direct impact |
| Suitable for | Hard rocks such as granite, basalt, silica | Semi-hard and medium-hard rocks, river rocks |
| Adjusting the grain size | Hydraulic and simple | Limited and usually by changing the screen mesh |
– High crushing efficiency for maximum output
– Uniform particle size for better product quality
– Durable design for long service life
– Adjustable output for different production needs
– Low maintenance and operating costs
– Reliable performance in heavy-duty conditions
Hydrocone; is a cone crusher used for secondary and tertiary crushing of hard and semi-hard rocks. With its conical design and hydraulic system, this device allows for uniform granulation and output size adjustment. Hydrocone is commonly used in granite, basalt, silica, iron ore mines and sand and gravel production lines.
Hydraulic machine repair includes checking and replacing wear parts (such as mantle, concave and head center), hydraulic parts (jack and hydraulic valve), bearings and other mechanical parts. Repair is usually done periodically and preventively to prevent production line downtime. Using original modern sand making machine parts and specialized technical services increases the life of the machine.
The choice of hydrocone size depends on the mine capacity, rock hardness, and crushing purpose. For medium to large iron ore mines, models with an inlet opening of 45 to 54 inches and a production capacity of 180 to 400 tons per hour are usually suitable. Novin Sand Making experts can recommend the optimal model based on the exact needs of the mine.
The hydrocone has compression and cone crushing and is suitable for hard and uniform rocks, while the cobit has impact crushing and is mostly used for semi-hard and soft rocks. The hydrocone has lower energy consumption and more uniform grain size, and its depreciation is lower than the cobit.
The hydrocone is equipped with a hydraulic system and a jack to adjust the opening. By changing the distance between the inner cone and the outer body, the size of the output product can be adjusted. This feature allows for precise granulation production for construction materials and sand and gravel production lines.
