Twin Shaft Batching Mixer is one of the most powerful concrete production mixers, which is used in construction projects and concrete component factories due to its high speed, excellent uniformity and excellent durability. Novin Sand Maker manufactures this machine with engineering design, anti-wear materials and full customization to exactly meet your project needs. All machines undergo heavy practical tests before delivery to prove their true quality.
| Technical specifications | Quantity / Description |
| Mixer type | Twin shaft twinning |
| Mixer capacity | 1 – 1.5 – 2 – 3 – 4 cubic meters per batch |
| Concrete production capacity | 60 to 180 cubic meters per hour (depending on model) |
| Number of shafts | 2 heavy alloy steel shafts |
| Mixer electric motor power | 30 to 75 kW (depending on capacity) |
| Gearbox type | Heavy duty, two independent gearboxes or central gearbox |
| Body and inner wall material | Wear-resistant steel |
| Blade and arm material | Manganese or wear-resistant steel with replaceable blades |
| Material weighing system | Digital with precise load cells of 1000 to 2000 kg |
| Cement weighing | Independent tank with digital load cell |
| Weighing water | Flowmeter or weighing tank |
| Control system | PLC automatic / semi-automatic / manual |
| Number of material feeder tanks | 2 to 4 tanks selectable |
| Feeding conveyor | 60–80 cm wide with a powerful motor |
| Concrete output | Hydraulic or pneumatic valve |
| Lubrication system | Automatic or semi-automatic |
| Input power requirement | Three-phase industrial 380 volts |
Twin Shaft Mixer: Uniform and fast mixing of materials to produce high quality concrete.
Dual steel shafts: Create simultaneous and powerful movement to thoroughly mix aggregate, water and cement.
Anti-wear blades and arms: Mix materials and increase the mixer’s resistance to permanent wear.
Heavy-duty gearboxes: Transfer power to the shafts and maintain a constant speed during mixing.
Industrial electric motor: Provide the necessary power for the shafts to rotate and the mixer to operate stably.
Anti-wear body and walls: Protect the mixer and prevent corrosion and impacts from aggregate.
Material inlet (feed hopper): Directs stone materials, cement and water into the mixer at a controlled flow rate.
Hydraulic concrete outlet: Quickly, reliably and uniformly discharges ready-mixed concrete after mixing is complete.
Electronic weighing system: Accurately measure cement, water, sand and gravel to produce standard concrete.
Control panel (PLC or semi-automatic): Manages batching processes, controls weighing, mixing time and production speed.
Feed conveyor: Transfers aggregates from the depot or feeder to the weighing section and then to the mixer.
Air compressor: Provides the necessary pressure to open and close the valves and clean the sections.
Automatic lubrication system: Reduces wear and tear on moving parts and increases the useful life of the mixer.
Material feeder (two or three chambers): Initial storage of sand and gravel and staged transfer to the weighing system.
At Novin Sand Maker, twin shaft batching plants are manufactured with engineering design and real industrial materials. The mixers are built with heavy alloy shafts, anti-wear blades, robust gearboxes and reinforced bodies to ensure the lowest wear and highest efficiency in continuous concrete production. All machines undergo several specialized testing stages before delivery: concrete mix test, vibration and balance test, shaft pressure test, continuous performance test and digital weighing and control system test to ensure that the batching plant is exactly the quality we claim.
Our services also make a real difference; from installation and commissioning, operator training, periodic service, parts supply, reliable warranty and fast technical support to constant support in the project. Most importantly, Novin Sand Maker designs and manufactures fully customized batching plants based on project needs; From mixer capacity to control type, number of feeders and complete line layout.
If you are planning to buy a quality, durable, and affordable twin-shaft batching plant, contact Novin Masesaz experts now to get complete advice before purchasing and choose the best option for your project.
The price of twin shaft batching is not fixed and is determined based on the capacity of the mixer, gearbox type, control system, number of material tanks and level of customization. In addition, fluctuations in the iron and equipment market have a direct impact on the final price. Therefore, it is not possible to provide an exact number without project specifications. To inquire about the current price and receive expert advice, contact the Novin Sand Making Machine sales team.
The choice of mixer capacity depends on the daily production volume and type of concrete. For structural and civil engineering projects, 1.5 to 2 cubic meters is usually suitable. For concrete component factories or mass production, capacities of 2 and 3 cubic meters are recommended. Novin Masesaz experts determine the exact capacity based on the workshop plan and project needs.
Twin shaft mixes concrete faster, more evenly and without lumps. The quality of slump and homogeneity of concrete in this mixer is not comparable to that of a pan or drum mixer. For high-strength concrete, fiber concrete and SCC concrete, the difference is quite measurable. For this reason, only twin shaft is used in sensitive projects.
Design and production time is between 10 and 20 working days depending on capacity and customization. After manufacturing, the technical team performs installation operations at the project site. Full commissioning and performance testing are carried out on the same day of installation. The total time is usually less than a month and a half.
Yes, Novin Sand Maker provides the opportunity to visit the production line and observe the manufacturing process. Also, before delivery, a complete test including concrete mixing, vibration, balance and continuous operation is carried out. You can be present at these tests. This ensures 100% confidence before purchasing.
The maintenance cost of this concrete production machine is very economical compared to its high efficiency. The blades, inner wall and bearings are the main consumable parts and are always available in the company’s warehouse. Novin Masesasaz offers periodic service, on-site support and fast delivery of parts. This means that your production line works without stopping.
