| Specification | Value / Description |
|---|---|
| Mixer Type | Twin-shaft, dual-axis |
| Batch Capacity | 1 – 1.5 – 2 – 3 – 4 m³ per batch |
| Concrete Production Capacity | 60–180 m³/h (depending on model) |
| Number of Shafts | 2 heavy-duty alloy steel shafts |
| Mixer Motor Power | 30–75 kW (based on capacity) |
| Gearbox Type | Heavy-duty; either two independent gearboxes or central gearbox |
| Body & Inner Wall Material | Wear-resistant steel |
| Blades & Arms Material | Manganese steel or wear-resistant steel, replaceable |
| Aggregate Weighing System | Digital with precise load cells (1000–2000 kg) |
| Cement Weighing | Independent silo with digital load cell |
| Water Weighing | Flowmeter or weight-based tank |
| Control System | Automatic PLC / Semi-automatic / Manual |
| Number of Aggregate Feeders | 2–4 selectable hoppers |
| Feeding Conveyor | 60–80 cm width, high-power motor |
| Concrete Discharge | Hydraulic or pneumatic gate |
| Lubrication System | Automatic or semi-automatic |
| Power Supply | Three-phase industrial 380 V |
Initial consultation and information exchange
Initial consultation and information exchange
Place an order
Product loading and shipping
The twin-shaft batching mixer is one of the most powerful concrete mixers, valued for its high speed, exceptional uniformity, and durability. It is widely used in civil engineering projects and precast concrete plants. Novinsm produces this machine with engineered design, wear-resistant materials, and full customization options to meet the exact needs of your project. All units undergo rigorous operational testing before delivery to ensure true performance.
Twin-shaft mixer: Ensures fast and uniform mixing for high-quality concrete production.
Dual steel shafts: Provide synchronized, powerful motion to thoroughly mix aggregates, water, and cement.
Wear-resistant blades and arms: Mix materials efficiently while protecting the mixer from continuous abrasion.
Heavy-duty gearboxes: Transmit power to the shafts and maintain consistent speed during mixing.
Industrial electric motor: Supplies required power for shaft rotation and stable mixer operation.
Wear-resistant body and lining: Protects the mixer from abrasion and impact from aggregates.
Material feed hopper: Guides aggregates, cement, and water into the mixer with controlled flow.
Hydraulic concrete discharge gate: Allows fast, reliable, and uniform discharge of ready-mix concrete.
Electronic weighing system: Accurately measures cement, water, sand, and gravel for standard concrete.
Control panel (PLC / semi-automatic): Manages batching stages, weighing, mixing time, and production speed.
Feeding conveyor: Transfers aggregates from stockpiles or feeders to the weighing section and then into the mixer.
Air compressor: Provides pressure for opening/closing gates and cleaning components.
Automatic lubrication system: Reduces wear of moving parts and extends mixer life.
Aggregate feeders (2 or 3 hoppers): Stores raw materials and feeds them in stages to the weighing system.
Uniform concrete mixing due to precise twin-shaft design and wear-resistant blades.
Extremely durable construction with thick steel plates and wear-resistant alloys.
Heavy-duty gearboxes support high loads and continuous operation.
Modular design allows easy access to consumable parts, reducing downtime and maintenance costs.
High mixing speed with continuous production capacity of 60–180 m³/h.
Highly accurate digital weighing system ensures quality control and minimizes human error.
Production of ready-mix concrete with medium to high capacity and consistent quality.
Large civil projects such as bridges, dams, and tunnels.
Precast concrete plants producing blocks, curbstones, beams, and other elements.
Specialized concrete production, including SCC, fiber-reinforced, and high-strength concrete.
Road and airport construction for continuous, large-volume concrete production.
Supply of concrete for continuous production lines in industrial factories and large construction sites.
Novinsm twin-shaft mixers are engineered with heavy alloy shafts, wear-resistant blades, reinforced bodies, and robust gearboxes to ensure minimal wear and maximum efficiency in continuous concrete production. Each mixer undergoes multiple pre-delivery tests: concrete mixing performance, vibration and balance, shaft stress, continuous operation, and digital weighing system checks to guarantee the claimed quality.
Our service differentiates us: installation, operator training, periodic maintenance, spare parts supply, warranty, and fast technical support. Novinsm also provides full customization based on project needs, including mixer capacity, control type, number of feeders, and complete line layout.
The price of a twin-shaft batching mixer is variable, depending on mixer capacity, gearbox type, control system, number of material hoppers, and level of customization. Market fluctuations in steel and equipment directly affect final pricing. For current pricing and expert consultation, contact the Novinsm sales team.
