| Characteristic | Description |
| Product name | 2-tier screen (double-tier vibration, from Novin Masesaz) |
| Origin and manufacturer | Made in Iran; Compatible with Kubit/Hydrocon crushing lines, capacity 50-100 tons/hour |
| Material and alloy | Body: ST37 steel (10-12 mm sheet); Mesh: wear-resistant steel (2-3 mm thick) or polyurethane; Springs: spring steel |
| Difficulty | HB 180-220 (steel body); Shore A 70-90 (polyurethane mesh) |
| Operating temperature | Maximum 50-80°C (resistant to heat, vibration and mineral environment) |
| Standard dimensions | Length: 5-6 meters; Width: 1.5-2 meters; Height: 2-3 meters; Floors: 2 (15-25 degree slope); Entrance opening: 100-150 cm |
| Approximate weight | 5-8 tons (depending on dimensions 2×6 meters and mesh material) |
| Production capacity | 50-100 tons/hour (depending on mesh size 350 microns-350 mm and vibration frequency) |
| Engine power | 10-15 kW (15 hp typical); 3-phase electric motor, 2-4 vibrators (750-1500 rpm) |
| Vibration frequency | 750-1500 revolutions per minute (rpm); Range: 5-10 mm (linear or circular) |
| Surface and tolerance | Surface finish: Ra 3.2-6.3 μm (body); Dimensional tolerance: ±0.03 mm; Mesh: 5-50 mm |
| Abrasion resistance | High (30% longer life with polyurethane mesh; resistant to mineral particles and precise sizing) |
| Thermal resistance | Excellent; resistant to continuous vibration and ambient temperature (anti-fatigue springs) |
| Processing type | Welding (body made of ST37 billet) + installation of mesh/spring; oil/grease for lubrication; 3 chute outlets |
Initial consultation and information exchange
Initial consultation and information exchange
Place an order
Product loading and shipping
Main: Granulation and separation of mineral/industrial materials after crushing, before salt sand; Output: 3 sizes (high >50 mm, medium 10-50 mm, fine <10 mm).
Industries: Sand/gravel mines, iron ore, cement, recycling, petrochemical (separation from 350 microns to 350 mm).
Types: Linear vibrator (common), grizzly (for coarse materials), rotary (for powder).
Precise separation with <2% loss, increased material quality (95% pollution reduction) and 30% longer screen durability.
Low energy consumption (10 kW), adjustable vibration; suitable for modern sand making lines (after Kubit).
Uniform texture, high safety (anti-vibration springs); flexible for floors 1-3.
Economical: Iranian production with OEM quality, easy installation (1 day).
Sensitive to high humidity (rusting screen; need anti-corrosion coating).
Consumable part (replace screen every 6-12 months in heavy duty).
Heavy weight (crane transport); sensitive to overload (decrease in efficiency >100 tons/hour).
In used models, springs may be fatigued (HB 180+ check).
Installation: on concrete base, 15-25 degree slope, connected to conveyor; leveling ±0.05 mm (1 day with crane).
Maintenance: Screen/spring inspection (every 200 hours), oil/grease lubrication; avoid sticky materials. Replace screen >5 mm wear.
Transportation: Maximum 10 tons for trailer (1 unit), 5 tons crane for installation.
